DLE430 430CC Two-Cylinder Two-Stroke Petrol Engine For Unmanned Aerial Vehicles Powered Parachutes Ultra Light Test Aircraft Gliding Airplane
| Part No.: | DLE430 |
| Manufacturer: | Feixiang |
Send to a friend
Features
DLE 430 is a two-cylinder two-stroke engine , can be used for unmanned aerial vehicles, powered parachutes, ultra light test aircraft, etc. It has the characteristics of light weight, long service life, big horse power, small vibration due to its unique structural design. A new design ideology— DLE 430 engine will give you an unprecedented experience.
Product Details
Diameter：70mm
Stroke：56mm
Displacement：430.8cc
Compression ratio：Theoretical 11∶1 effective 6.5∶1
Speed Reducing ratio：2.55
Power：42HP at 6800 RPM
Static thrust：110kg
Maximum RPM：7000 RPM
Idle speed：1000 RPM
Spark plug type：14mm DLE-8
Spark plug gap：0.6MM
Carburetor：DLE Self-priming
Fuel：Gasoline 93# 97#
Fuel mixed oil：2T FD full synthesis
Oil mixture ratio：50：1
Lubrication oil of gear-box：Gear oil , 85W-140EP API-GL5 GL6 SAE 140 EP
Ignition system：Double set DC capacitor discharge ignition,12v power supply , 5W/piece
Generated power：Permanent magnet generator 14.5V 90W
Starting motor current：35A
Rotation direction：Clockwise
Radiator：Fan cooling
Weight：Main engine : 27kg Exhaust : 4.1kg Totally : 32.25 kg
Recommended Propeller： 1.5M Variable pitch carbon-fiber propeller
Stroke：56mm
Displacement：430.8cc
Compression ratio：Theoretical 11∶1 effective 6.5∶1
Speed Reducing ratio：2.55
Power：42HP at 6800 RPM
Static thrust：110kg
Maximum RPM：7000 RPM
Idle speed：1000 RPM
Spark plug type：14mm DLE-8
Spark plug gap：0.6MM
Carburetor：DLE Self-priming
Fuel：Gasoline 93# 97#
Fuel mixed oil：2T FD full synthesis
Oil mixture ratio：50：1
Lubrication oil of gear-box：Gear oil , 85W-140EP API-GL5 GL6 SAE 140 EP
Ignition system：Double set DC capacitor discharge ignition,12v power supply , 5W/piece
Generated power：Permanent magnet generator 14.5V 90W
Starting motor current：35A
Rotation direction：Clockwise
Radiator：Fan cooling
Weight：Main engine : 27kg Exhaust : 4.1kg Totally : 32.25 kg
Recommended Propeller： 1.5M Variable pitch carbon-fiber propeller
Item Packing
DLE430 430CC Two-Cylinder Two-Stroke Petrol Engine x 1
Detailed Images
