New 3DR Radio V2.0 Telemetry Kit 915Mhz Module For APM PX4 Aerial Photography

New 3DR Radio V2.0 Telemetry Kit 915Mhz Module For APM  PX4 Aerial Photography
Part No.: FPV-Telemetryv2.0915
Manufacturer: hymodel

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

The new 3DR Radio V2.0 digital ground-side and air-side modules use the same design. Each module can be used as a ground terminal or an air terminal. Each has a Micro USB connector, which greatly reduces the cost of use and makes the new enclosure more attractive. The shipment is equipped with 2 types of cables, 5pin for APM and 6pin for Pixhawk.

The 3DRobotics 3DR radio is an ideal way to set up a telemetry connection between the APM and the ground station. Its small size, low price, and wide range of use of open source firmware allow us to do things that other radio stations cannot.

Product Details

Very small
Lightweight (without antenna only 4g)
Optional: 915HZ
Receiver sensitivity of -121 dBm
Transmission power is 20dBm (100mW)
Transparent serial link
Data rate up to 250kbps in the air
MAVLink protocol frame and status report
Frequency Hopping Spread Spectrum (FHSS)
Adaptive Time Division Multiplexing (TDM)
Supports LBT and AFA
Configurable duty cycle
Built-in error correction code (can correct up to 25% of data bit errors)
Use a small omnidirectional antenna up to several kilometers
Bidirectional amplifiers available for greater range
Open source firmware
AT command configuration pass
RT command remote configuration data transfer
Adaptive flow control when used with APM
Based on HM-TRP wireless module with Si1000 8051 microcontroller and Si4432 wireless module.

Item Packing

New 3DR Radio V2.0 Telemetry Kit 915Mhz Module For APM  PX4 Aerial Photography x 1
