Rocket 3680 1100KV 4 Poles Brushless Sensorless Motor for 800-1000mm RC Boat

Rocket 3680 1100KV 4 Poles Brushless Sensorless Motor for 800-1000mm RC Boat
Part No.: RO-3680-1100KV
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

4 Pole 12 slot hi-torque motor design
CNC machined 6061 T6 billet aluminum heatsink can
High purity copper windings maximizes efficiency
High RPM ABEC5 oversized bearings
Precision balanced rotor, smoothness for best reliability and maximum RPM
Stator-super thin (0.2mm) laminations
Removable/replaceable rotor
Precision engineered for maximum energy conversion

Product Details

Brand name: Rocket
KV(RPM/Volt): 1100KV
Diameter: 36mm
Length: 80mm
Shaft diameter: 5mm
Connector: 4mm golden banana connector
Max Amps:60
Max voltage:34
Max power(W):2000
Weight(g):320
Motor size(mm) :Φ36x80
Winding type:WYE
Number of turns:3.5Y
No load current:1.6A
Max RPM:50K
Shaft(mm):Φ5
Rotor poles:4

Item Packing

Rocket 1100KV Brushless Motor x 1
