Hobbywing X11 MAX Motor Power System 11122 18S 60KV 48175 Propeller CW for Multirotor Agriculture Drone

Hobbywing X11 MAX Motor Power System 11122 18S 60KV 48175 Propeller CW for Multirotor Agriculture Drone
Part No.: X11-MAX-CW
Manufacturer: Hobbywing

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

Hobbywing X11 MAX Motor Power System 11122 18S 60KV 48175 Propeller CW for Multirotor Agriculture Drone

Product Details

Product Name: XRotor X11-MAX
Specifications
Max. Thrust: 44kg/Axis (70V, Sea Level)
Recommended Takeoff Weight: 20-22kg/Axis (46V, Sea Level)
Recommended LiPo Battery: 18S(LiPo)
Operating Temperature: -20~50℃
Combo Weight: 2800g
Waterproof Rating: IPX6

Motor
Steering: CW
KV Rating: 60 rpm/V
Stator Size: 111*22mm
Powertrain Arm Tube Outer Diameter: 50mm
Bearing

ESC
Recommended LiPo Battery: 18S(LiPo)
PWM Input Signal Level: 3.3V/5V
Throttle Signal Frequency: 50-500Hz
Operating Pulse Width: 1050-1950-us(Fixed or cannot be Programmed)
Max. Input Voltage: 78.3V
Max. Input Current (Short duration): 150A(w/ Good Heat Dissipation)
BEC: No

Propeller
Diameter×Pitch: 48*17.5

Item Packing

Hobbywing X11 MAX Motor Power System CW x 1set

Detailed Images
