T-Motor F60 Pro IV 1750KV 4-6S Brushless Motor for RC Drone FPV Racing








T-Motor F60 Pro IV 1750KV 4-6S Brushless Motor for RC Drone FPV Racing
Diffirence from Pro III Version:
1. Lighter & Quicker response
– Crafted product, reducing weight at every detail. 9% less weight compared with F60PROIII-
– Internal motor pinhole (0.05g less)
– 12MM steel shaft (0.4g less)
– Customized silicone wire(0.4g less)
– Silicon steel sheet ( redesign to less 0.5g)
– Other (0.2g less)
2. Durability Enhanced greatly
– Interlaced rib design
– Shaft height is reduced to 12MM
– Special base design
3.Improve user experience at every detail
– Customized prop nut to protect the shaft thread effectively
– Optimized mounting holes perfectly match the frames/arms
Brand Name: T-motor
Model: F60 Pro IV
KV: 1750KV
Color: Red/ Gray/ Blue ( Optional)
Version: CW Screw Thread
Shaft Diameter: 4mm
Configuration: 12N14P
Input Voltage: 4-6S
Idle Current(10V): 1.2A
Burst Current(60S): 39A
Internal Resistance: 65mΩ
Max. Power(60S): 940W
Dimension: 27.1×31.1mm
Weight: 32.5g
T-Motor F60 Pro IV 2207 1750KV Motor x 1
