Item： S23M
Gear： Steel gear
Spline： 25T
Motor： Coreless motor
Bearing： 2BB
Dead band： 2μs default
Waterproof： No
Operating Voltage： DC5.0~8.4V
Rated working voltage： DC 7.4V
Working frequence： 1520μs/330hz
Working angle： ±63°@800us-2200us
Working temperature： -10℃~+50℃
Storage temperature： -20℃~+60℃

SPECIFICATIONS:
Operating Speed(5.0V):0.10sec/60degrees
Operating Speed(6.0V):0.08sec/60degrees
Operating Speed(7.4V):0.07sec/60degrees
Operating Speed(8.4V):0.06sec/60degrees
Stall torque(7.4V):23.0kg.cm(319.47oz/in)
Rated working torque(5.0V):4.60kg.cm(63.89oz/in)
Rated working torque(6.0V):4.90kg.cm(68.06oz/in)
Rated working torque(7.4V):6.00kg.cm(83.34oz/in)
Rated working torque(8.4V):7.00kg.cm(97.23oz/in)
Dimensions(L*W*H):36*15*33mm/1.40X0.58X1.28in
Weight:50.5g(1.78oz)
Connector Wire Length:JR220mm(8.58in)
Packing Detail:
Transparency plastic box size: 83.5mmx63.5mmx37.5mm   weight: 102.5g
Carton box   size: 43×26.5×20.5cm   100sets/1CTN   Cross weight:10.25kg
