It takes quite a servo to impress us at ServoCity but the HSR-5980SG does just that. This servo raises the bar when it comes to servo technology. The performance is staggering for a servo this size especially when installed in our ServoPower Gearbox (over 2,000 oz-in. or torque). Right out of the box, this servo operates a full 140° (full trims). A full set of steel gears offers 30 times the strength of nylon gears. Each gearset shaft rides in bronze bushings for durability and strength. We offer the HSR-5980SG servo in two configurations, continuous rotation (potentiometer is left outside the servo case) and reverse rotation. We know that this is not a cheap servo but you definitely get what you pay for – you will be impressed!
Control System: +Pulse Width Control 1500usec Neutral
Required Pulse: 3.3-7.4 Volt Peak to Peak Square Wave
Operating Voltage Range: 4.8-7.4 Volts
Operating Temperature Range: -20 to +60 Degree C (-68F to +140F)
Operating Speed (6.0V): 0.15 sec/60° at no load
Operating Speed (7.4V): 0.12sec/60° at no load
Stall Torque (6.0V): 333.29 oz-in. (24kg.cm)
Stall Torque (7.4V): 416.61 oz-in. (30kg.cm)
Standing Torque (6.0V): 433.27 oz-in. (31.2kg.cm) 5 degree deflection
Standing Torque (7.4V): 541.59 oz-in. (39kg.cm) 5 degree deflection
Operating Angle: 60 Deg. one side pulse traveling 450usec
360 Modifiable: Yes
Direction: Clockwise/Pulse Traveling 1450 to 1950usec
Idle Current Drain (6.0V): 3mA at stop
Idle Current Drain (7.4V): 3mA at stop
Current Drain (6.0V): 300mA/idle and 4.2 amps at lock/stall
Current Drain (7.4V): 380mA/idle and 5.2 amps at lock/stall
Dead Band Width: 2usec
Motor Type: Coreless Metal Brush
Potentiometer Drive: 6 Slider Indirect Drive
Bearing Type: Dual Ball Bearing MR106
Gear Type: 4 Hardened Steel Gears
Connector Wire Length: 11.81″ (300mm)
Dimensions: 1.57″ x 0.78″x 1.45″ (40 x 20 x 37mm)
Weight: 2.18oz (62g)
Hitec HSR-5980SG Servo x1
