Model: FT-1108-C001
Storage temperature range: -20℃～70℃
Operating temperature range: -20℃～60℃
Size: 21.2*11.4*20.2mm
Weight: 9.8±1g
Gear type: Metal gear
Limit angle: No limit
Bearing: Ball bearings
Horn gear spline: 25T/3.95mm
The rocker phantom: 0°
Case: Aluminum
Connector wire: 6.5±0.5cm
Motor: Coreless motor
Operating voltage range: 4.8-7.4V
Idle current (at stopped): 6mA@6V
No load speed: 0.055sec/60°@6V
Running current(at no load): 90mA@6V
Peak stall torque: 2.5kg.cm@6V
Rated torque: 0.7kg.cm@6V
Stall current: 0.9A@6V
Command signal: Pulse width modification
Amplifier type: Digital comparator
Pulse width range: 500~2500usec
Stop position: 1500μsec
Running degree: 180° (at 500→2500μsec)
Dead band width: ≤4μsec
Rotating direction: Counterclockwise (at 500→2500μsec)
