4PCS BrotherHobby Special Edition V4 32.5-12 580KV Motor Brushless Motor For 9-13Inch FPV Long Rang Racing Drone X9 X13
4PCS BrotherHobby Special Edition V4 32.5-12 580KV Motor Brushless Motor For 9-13Inch FPV Long Rang Racing Drone X9 X13
*Adopts aviation-grade 7075 AL caps with hard anodized treatment. Slight scraping leaves no trace.
*Equipped with NMB bearings.
*Uses TU1 grade enameled wire with high full slot ratio and low internal resistance.
*Has a titanium alloy shaft.
*Utilizes N52h arc magnets with consistent air gap, stable magnetic circuit and linear torque.
KV value: 580KV
Slot-pole: 12N14P
Outer diameter of silicon steel sheet: 32.50mm
Motor installation size: Φ38.2 x 45.7mm
Silicone wire number and length (AWG): 16# silicone wire, 250mm
Height of silicon steel sheet: 12mm (Nippon Steel)
Motor weight (including wire): 92.60g
Magnet grade: N52H
Phase-to-phase resistance: 100.00mΩ
No-load current (A)/(voltage 10V): 1.06A/10V
Rated voltage (lithium battery): 6S
Maximum power: 937.50W
Maximum current: 37.50A
Overall motor balance standard: ≤3mg
Insulation resistance: ≥0.5MΩ
Coil test: Qualified
Recommended ESC: 6S 45A
Recommended propeller: GF13x8x3 glass fiber nylon.
4x BrotherHobby 580KV Motor Brushless Motor
