500mm S500 SK500 Quadcopter Multicopter Frame Kit PCB Version with 260mm Carbon Fiber Landing Gear
![500mm S500 SK500 Quadcopter Multicopter Frame Kit PCB Version with 260mm Carbon Fiber Landing Gear](/pic/202111/6571_sml.jpg)
Part No.: | S550-260MM |
Manufacturer: | Feixiang |
Send to a friend
Features
- F450 upgrade quadcopter
- Learned arm design from DJI S800 EVO, and enhanced
- good work with DJI H3-2D gimbal
- PCB Center plate with solder point
- high quality carbon fiber landing gear
- Frame only, no electronic parts.
- Learned arm design from DJI S800 EVO, and enhanced
- good work with DJI H3-2D gimbal
- PCB Center plate with solder point
- high quality carbon fiber landing gear
- Frame only, no electronic parts.
Product Details
- Wheelbase: 485mm
- Landing Gear Vertical Height: 260mm
- Motor suggest: 2212 KV980; 2216 KV880 KV900; 3108 900KV (not include)
- Prop suggest: 1045/1047/1147/1238 (not include)
- Battery suggest: 3S-4S 2200mAh-5200mAh (not include)
- Landing Gear Vertical Height: 260mm
- Motor suggest: 2212 KV980; 2216 KV880 KV900; 3108 900KV (not include)
- Prop suggest: 1045/1047/1147/1238 (not include)
- Battery suggest: 3S-4S 2200mAh-5200mAh (not include)
Item Packing
S500 Quadcopter Frame Kit with 260mm Landing Gear x 1
Detailed Images
![](/pic/dimg/202111/6571_dimg1.jpg)
![](/pic/dimg/202111/6571_dimg2.jpg)
![](/pic/dimg/202111/6571_dimg3.jpg)
![](/pic/dimg/202111/6571_dimg4.jpg)
![](/pic/dimg/202111/6571_dimg5.jpg)
![](/pic/dimg/202111/6571_dimg6.jpg)
