NEW ISDT K2 Air AC 200W DC 500Wx2 20A Dual Channel Balance Lipo Charger Discharger for Lipo NiMh Pb Battery

NEW ISDT K2 Air AC 200W DC 500Wx2 20A Dual Channel Balance Lipo Charger Discharger for Lipo NiMh Pb Battery
Part No.: ISDT-K2Air
Manufacturer: ISDT

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

NEW ISDT K2 Air AC 200W DC 500Wx2 20A Dual Channel Balance Lipo Charger Discharger for Lipo NiMh Pb Battery

Product Details

Input voltage range: AC 100-240V / DC 10-30V
Output voltage range: DC 1-30V
Maximum input current: DC 35A
Charging current: 0.2~20A x2
Discharge current: 0.2~1.5A x2
Maximum charging power: AC 200W / DC 500W x2
Maximum discharge power: 15W x2
Balance current: 1.5A / Cell Max
Supported battery types and cell count: Life , Lilon , Lipo , Lihv 1-6S; Pb 1-12s; NIMH / Cd 1-16S
Parallel charging power and current: 800W / 35A
Parallel discharge power and current: 30W / 3A
USB output: 5-20V / 30W
Operating temperature: 0-40°C
Storage temperature: - 20-60°C
Dimension: 135x135x64mm
Weight: about 700g

Item Packing

ISDT K2 Air Balance Charger x 1
